Subsea Umbilical Reels and Systems

Subsea umbilical reels are available in a wide size range from 3 inches to 96 inches (75mm to 2400mm) in diameter. Sizes and configurations are manufactured to customer specifications, ensuring the reel dimensions precisely match the umbilical cable diameter, length, and deployment system requirements of your offshore project.

Yes. Fabricated Steel Reels and Fully Machined Steel Reels are manufactured in compliance with DIN 46395 and DIN 46397 standards as applicable. Heat-treated materials are also available for export compliance. All reels are built to customer specifications and supplied with engineering drawings to ensure traceability and quality assurance.

Dynamic balancing ensures that the reel rotates evenly under load without vibration or wobble. For subsea and offshore operations, this is critical to achieving controlled, consistent payout and retrieval of heavy umbilical cables. Dynamically balanced reels reduce wear on deployment equipment and improve operational safety on offshore vessels and platforms.

Absolutely. All subsea umbilical reels are manufactured to customer-supplied specifications. Narco's in-house welding, machining, and fabrication capabilities allow for custom drum diameter, traverse width, arbor hole size, flange configuration, and load capacity. Engineering drawings are supplied with every quote and order to confirm alignment with your design requirements before production begins.

Yes. New American Reel Co LLC offers reconditioning, repair, and welding services for existing steel reels, extending their operational life and reducing replacement costs. This is particularly valuable for high-value subsea umbilical reels that undergo repeated offshore deployment cycles. Contact Narco to discuss the condition and refurbishment scope for your existing reel inventory.

Lead times vary based on reel size, complexity, and order volume. Narco provides technical consultation and supplies engineering drawings at the quoting stage to streamline the approval process. For inquiries, contact the team directly at 419-258-2900 or mark@narco.us. The team is available Monday through Friday, 7 a.m. to 3:30 p.m.
